Optical film options
特色
MOE는 다양한 맞춤형 광학 필름을 제공하거나 아래에 표시된 현재 표준 필름을 사용할 수 있습니다.
Photo Lithograophy 공정과 광학 코팅의 통합을 통해 다양한 통합 광학 부품을 완성할 수 있습니다.
Photo Lithograophy 공정과 광학 코팅의 통합을 통해 다양한 통합 광학 부품을 완성할 수 있습니다.
BM
Product Description
With high shading properties and ultra-low reflection, and it can prevent stray light.
Explaination 1
Competitive advantages:
Different manufacturing methods can be adopted according to customer needs
1. Evaporation
2. Photoresist coating
Explaination 2
Product applications:
‧Camera Modules
| Specification | Criteria | ||||
| 450~950nm Tmax (%) | = 0% | ||||
| Specification | Criteria | ||||
| 400~600nm Rabs (%) | < 3.0% | ||||
| 450~950nm Ravg (%) | < 3.0% | ||||
| 950~1000nm Rabs (%) | < 7.0% | ||||
IR
| Specification | Criteria | ||||
|---|---|---|---|---|---|
| Normalized Cut-on T50% (nm) | 395 nm | ||||
| Normalized Cut-off T50% (nm) | 660 nm | ||||
| 430-570nm, Tmax(%) | >70% | ||||
| 800-1100nm, Tavg (%) | <1.5% | ||||
IR-BAND PASS
| Specification | Criteria | ||||
| Normalized Cut-on T50% (nm) | 820 ± 15 nm | ||||
| Normalized Cut-off T50% (nm) | 880 ± 15 nm | ||||
| Peak Transmission (%) | 45 ± 3% | ||||
| Peak T% Range (nm) | 850 ± 10 nm | ||||
| 500-770nm Tavg | < 1.0% | ||||
| 930-1100nm Tavg | < 1.0% | ||||
IR940
| Specification | Criteria | ||||
| Normalized Cut-on T50% | 905 ± 8nm | ||||
| Normalized Cut-off T50% | 985 ± 8nm | ||||
| Peak Transmission (%) | 50 ± 5% | ||||
| Peak T% Range (nm) | 940 ± 10nm | ||||
| 400~830nm Tavg (%) | < 0.5% | ||||
| 400~500nm Tabs (%) | < 3.0% | ||||
| 1050~1100nm Tavg (%) | < 2.0% | ||||
| Specification | Criteria | ||||
| λC (nm) | 950-965 nm | ||||
| Peak Transmission (%) | > 45% | ||||
| Tavg on 300~850nm (%) | < 0.7% | ||||
| Tavg on 1080~1100nm (%) | < 5% | ||||
| Nor. BW T50% (nm) | >90nm | ||||
| Nor. Cut-on T50% (nm) | - | ||||
| Nor. Cut-off T50% (nm) | - | ||||
IR550
| Specification | Criteria | ||||
| Normalized Cut-on T50% (nm) | 500 ±8 nm | ||||
| Normalized Cut-off T50% (nm) | 595 ±8 nm | ||||
| Peak Transmission (%) | 60 ±5% | ||||
| Peak T% Range (nm) | 545 ±10nm | ||||
| 300nm~420nm Tavg (%) | < 2.0% | ||||
| 720nm~780nm Tabs (%) | < 1.5% | ||||
| 780nm~1100nm Tabs (%) | < 0.5% | ||||
| 720nm~1100nm Tavg (%) | < 0.5% | ||||
IRCF
| Specification | Criteria | ||||
| Cut-on T50% (nm) | 410 ± 10 nm | ||||
| Cut-off T50% (nm) | 680 ± 10 nm | ||||
RBG
| Specification | Criteria | ||||
| Peak T% Range (nm) | 645 ± 10 nm | ||||
| Peak Transmission (%) | > 61% | ||||
| 790-1100nm Tavg (%) | < 1.0% | ||||
| Bandwidth from Normalized Cut-on & Cut-off T50% (nm) | >105 nm | ||||
| Normalized Cut-on T50% | - | ||||
| Normalized Cut-off T50% | - | ||||
B spec
| Specification | Criteria | ||||
| Peak T% Range (nm) | 455 ± 10 nm | ||||
| Peak Transmission (%) | > 50% | ||||
| 580nm-1100nm Tavg (%) | < 1.0% | ||||
| Bandwidth from Normalized Cut-on & Cut-off T50% (nm) | > 75 nm | ||||
| Normalized Cut-on T50% (nm) | - | ||||
| Normalized Cut-off T50% (nm) | - | ||||
G spec
| Specification | Criteria | ||||
| Peak T% Range (nm) | 580 ± 10 nm | ||||
| Peak Transmission (%) | > 60% | ||||
| 300-450nm Tavg (%) | < 2.5% | ||||
| 800-1100nm Tavg (%) | < 0.5% | ||||
| Bandwidth from Normalized Cut-on & Cut-off T50% (nm) | > 100 nm | ||||
| Normalized Cut-on T50%(nm) | - | ||||
| Normalized Cut-off T50% (nm) | - | ||||
UVA
| Specification | Criteria | ||||
| Peak T% Range (nm) | 365 ± 7 nm | ||||
| Peak Transmission (%) | > 20% | ||||
| 420-520nm Tmax (%) | < 0.50% | ||||
| 600-1100nm Tmax (%) | < 0.10% | ||||
